Model Number: OD-TRSS-48300/OD-TRSS-48600 Input AC voltage range:176Vdc～300Vac  Output DC voltage range: -43.2Vdc~ -57.6Vdc (Typical value-53.5Vdc) Storage temperature Range: －45℃～＋70℃   Application field: Communication Base Station

Model: CNW4850L  Nominal Capacity:3KW-5KW Nominal Voltage: 48VDC, 120VAC/230VAC  Install Method: Pole Mount, Wall Mount, Floor Installation   Application field Traffic Lights CCTV Road Monitor Camera Other outdoor field

Model Number: CNHR112 1-3KVA Nominal Capacity: 1 – 3KVA Nominal Voltage: 220VAC Maximum Input Voltage Range: 90 – 300VAC Nominal Frequency: 50/60HZ   Application field: Data Center Telecom Local Area Networks Servers

Model: CNW110-1K  Nominal Voltage: 220VAC Nominal Frequency: 50/60HZ Installation Method: Pole-Mounted / Wall-Mounted   Application field: CCTV Traffic Lights Road Monitors Telecom

Model: CNW110L-1K Nominal Voltage: 240VAC Nominal Frequency: 50/60HZ Installation Method: Pole-Mounted / Wall-Mounted   Application field: CCTV Traffic Lights Road Monitors Telecom

Model Number: CNW110 1-3KVA Nominal Capacity: 1 – 3KVA Nominal Voltage: 220VAC Maximum Input Voltage Range: +-20% Nominal Frequency: 50/60HZ   Application field: CCTV Traffic Lights Telecom

Model Number: CNW110 1-3KVA Nominal Capacity: 1 – 3KVA Nominal Voltage: 220VAC Maximum Input Voltage Range: ±20% Nominal Frequency: 50/60HZ   Application field: CCTV Traffic Lights Telecom

Model Number: CNW110 1-10KVA Nominal Capacity: 1 – 10KVA Nominal Voltage: 220VAC Maximum Input Voltage Range: +-20% Nominal Frequency: 50/60HZ   Application field: CCTV Traffic Lights Telecom

Model Number: CNW110 1-10KVA Nominal Capacity: 1 – 10KVA Nominal Voltage: 220VAC Maximum Input Voltage Range: +-20% Nominal Frequency: 50/60HZ   Application field: CCTV Traffic Lights Telecom

Model Number: CNW310 6-10KVA Nominal Capacity: 6 – 10KVA Nominal Voltage: 220VAC Maximum Input Voltage Range: +-20% Nominal Frequency: 50/60HZ   Application field: CCTV Traffic Lights Telecom

SPECIFICATION: Model Number: TSS-48400 System capacity：8U400A Input voltage range： 120~425Vdc Output voltage：-53.5Vdc Output current： 400A （MAX） Output capacity: 24KW (MAX) Solar modules quantity: 1~8pcs   CONFIGURATION: Pv input: MCB 25A / 2P * 8, DC-SPD * 8 Battery access: MCB 125A / 1P * 4 DC output: DC-SPD * Class 1-C Secondary load disconnect: MCB 100A / 1P * 2,63A / 1P * 4,32A / 1P * 2 Primary load disconnect: MCB 63A / 1P * 2,32A / 1P * 2,16A / 1P * 2 Secondary load disconnect is controlled by the 400A contactor (normally closed) Primary load disconnect is controlled by the 200A contactor (normally closed) Note: above configurations can be customized.   Application field: Telecom; Data center

SPECIFICATION: Model Number:TRSS-48300 System capacity：9U300A   Solar Charge Controller Module: Input voltage range： 120~425V Output voltage：-54.5Vdc Output current： 300A （MAX） Output capacity: 18KW (MAX) Solar module quantity: 1~6pcs Rectifier modules: Input voltage range： 176~300V Output voltage：-53.5Vdc Output current： 300A （MAX） Output capacity: 18KW (MAX) Solar module quantity: 1~6pcs   CONFIGURATION: AC input: MCB 63A / 3P * 1, UK35 * 1 PV input: MCB 25A / 2P * 6, DC-SPD * 6 Battery access: MCB 125A / 1P * 3 Primary load disconnect: MCB 125A/1P*3, 63A/1P*3 Primary load disconnect is controlled by a 400A contactor (normally closed) Configuration: AC Class C 3 + 1 mode 20 KA / 40 KA SPD * 1, DC output lightning protection: Class C DC SPD * 1 Note: above configurations can be customized.   Application field: Telecom; Data center
