Wall Mount LiFePO4 Battery Pack 48V 100AH

Wall Mount LiFePO4 Battery Pack  48V 100AH

CNS-LFP48100-WM

Nominal Capacity: 100Ah
Nominal Voltage: 48V
Cycle life:DOD(≥1800 cycles at 85% DOD)

Communication mode:SMBuS/RS485/RS232/CAN



Application field:

Home energy storage system

Communication base station

Data center

Indoor distribution stations

Integrated base stations

Marginal stations

Distributed power supply







  • Item No :

    CNS-LFP48100-WM
  • Order(MOQ) :

    10 pcs
  • Payment :

    T/T
  • Product Origin :

    China
  • Color :

    White
  • Shipping Port :

    Shenzhen
  • Lead Time :

    1 weeks
  • Weight :

    45 Kg

Wall Mount LiFePO4 Battery Pack  48V 100AH

Description



Product Characteristics:

● High output, high energy density, high cycle life, small internal resistance.

● Lighter weight, about 40% of the weight of lead-acid battery, is an alternative to lead-acid battery, safe and reliable explosion-proof exhaust system.

● The positive and negative plate gate is made of lead-calcium multicomponent alloy,corrosion resistance,no pollution and less water consumption.

● High-sensitivity safety valve can effectively improve the safety of the battery at work.

● With communication function,R232\R485\CAN,real-time and historical data query.

● Up to 15 units can be connected in parallel.



Application:

Home energy storage system,

communication base station,data center



Technical Parameters:

Model  CNS-LFP48100-WM CNS-LFP48200-WM
 Electrical Rated voltage(VDC) 51.2 51.2
Rated capacity (AH) 100 200
Energy storage (KWH) 5.12 10.24
Internal resistance <50mΩ
Cycle life DOD(≥1800 cycles at 85% DOD)
Self discharge ≤2%
Charge efficiency 100% at 0.2C
Discharge efficiency 96~99% at 1C
 Charge Charge voltage 58.4±0.2V
Charge  mode 0.2C equalized charge, then 58.4V constant-voltage charge, then floating charge at 0.02C
Charge current 20 40
Maximum charge current(A) 50 100
Maximum charge voltage (DC) 58.4V
 Discharge Continuous current(A) 20 40
Discharge termination voltage (DC) 44.8V
 Environmental Charge temperature 0℃ to 45℃(32F to 113F)@60±25% Relative Humidity
Delivery temperature -20℃ to 60℃(-4F to 140F)@60±25% Relative Humidity
Storage temperature 0℃ to 40℃(32F to 104F)@60±25% Relative Humidity
 Physical Material LiFePO4
Case material Metal
Size:   L*W*H(mm) 555x390x150 590x375x250
Weight(KG) 45 85
Terminal M8
Communication SMBuS/RS485/RS232/CAN
Display LED/LCD
