Wall Mount LiFePO4 Battery Pack 48V 200Ah

Wall Mount LiFePO4 Battery Pack 48V 200Ah

Nominal Capacity: 200Ah
Watt Hour: 9600Wh
Nominal Voltage: 48V
Operating voltage range: 37.5V~54.75V
Communication mode: RS485



Application field

Indoor distribution stations

Integrated base stations

Marginal stations

Distributed power supply

  • Item No :

    48V 200Ah
  • Order(MOQ) :

    10 pcs
  • Payment :

    T/T
  • Product Origin :

    China
  • Color :

    RAL7035
  • Shipping Port :

    Shenzhen
  • Lead Time :

    1 week
  • Weight :

    118 Kg

Wall Mount LiFePO4 Battery Pack 48V 200Ah

Description

This product is a new type of backup power supply for the development of high-tech products, with integration, miniaturization, light, intelligent, standardized, environmental protection and other characteristics, can be widely used in indoor distribution stations, integrated base stations, marginal stations, distributed power supply and other fields.

Adopted by the high safety performance, lithium battery cathode material for lithium iron phosphate, high safety, high stability, high cycle life, high specific energy, specific power, low temperature performance is superior, but large current charge and discharge, and many other advantages, at the same time, using suitable for communication demand special high performance battery management system (BMS), with the charge, over discharge, short circuit, over-current (load), temperature, flow, total pressure protection, charging under the secondary electricity, balanced and various protective functions, and provides CAN 、 RS485 communication interface and the upper machine to realize remote monitoring, can be connected to the base station power environmental monitoring systems,Intelligent software anti-theft design,Ensure the life of lithium battery and reduce the daily maintenance work.

Product features:

 • The internal single battery adopts the anode material of lithium ferrous phosphate (LiFePO4), which has high safety, high energy density and excellent cycling performance;

 • The battery pack is equipped with BMS, a high-performance battery management system, which has the protection functions of over discharge, over charge, over current, high temperature and low temperature to ensure the safety of the battery pack;

 • Automatic charge and discharge management. The monitoring unit automatically measures the charge and discharge current of the battery and manages the floating charge and even charge of the battery;

 • When the battery voltage is lower than the alarm value, it will alarm, and when the voltage is too low, it will automatically power down to protect the battery;

 • The battery pack has good electromagnetic compatibility;



Technical Parameters:

Nominal Capacity 200Ah
Watt Hour 9600Wh
Nominal Voltage 48V
Operating voltage range 37.5V~54.75V
Standard charging method 50A
Maximum
continuous charging current
100A
Cycle Life ≥3000 cycles (0.5C charge ,0.5C discharge)
80%DOD;±25℃
Operating Temperature -20℃-60℃
Storage Temperature -20℃-50℃
Communication mode RS485
Shipment voltage ≥48V
Charge retention and
capacity recovery capability
Standard charge the battery, and then put aside at room temperature for 28d or 55 ℃ for 7d,
Charge retention rate≥90%, Recovery rate of charge≥90
Weight 118KG
Size (W575×H764×D190mm )±5mm
Designed life 10years
Guarantee period 3years
