Model: CNW4850L-5KW Nominal Capacity:5KW Nominal Voltage: 48VDC, 230VAC  Install Method: Pole Mount, Wall Mount, Floor Installation   Application field: Traffic Lights CCTV Road Monitor Camera Other outdoor field

Model：CNME331 60-120K Capacity: 60-150KVA Input Voltage Range：138～485Vac Output Rated Voltage：380/400/415Vac   Application： Data centers; Small server room, Network, Bank, Security, Transportation, Broadcast&TV network, HealthCare, Communication, Finance，Small and medium-sized substations and power plants; Production process control in manufacturing and petrochemical industries, etc.

(High Voltage) Model: TS-4850H Capacity：50A Input: 120-425Vdc Output: 42-58Vdc

(Low voltage) Model:TS-4850L Capacity：52A Input: 68-150Vdc Output: 43.2-58Vdc

Model: TI-2000HV Capacity：2KW Input Voltage Range: 176Vac～265Vac(176V-200V linear drop) Input Voltage Range: 42Vdc~58Vdc Output Voltage: Rated 220/230/240Vac(output voltage optional)

High voltage rectifier module Model: TR-4830/50/75 Capacity：30A/ 50A / 75A Output: 42-58Vdc   30A  Input: 85-300Vac  Efficiency: 92% or 93% 50A  Input: 85-300Vac or 120-400Vdc  Efficiency: 95% or 96% 75A  Input: 85-300Vac   Efficiency: 96.6%

  Model: OD-TISS4850 Nominal Voltage:220/230/240VAC Nominal Frequency: 50/60Hz Output Power Factor: 1.0 Use temperature Range: －40℃～＋50℃   Application field: Local Area Telecom Traffic Lights Networks CCTV

Model: CNS110 4200-24/CNS110 6200-48 Nominal Capacity: 4.2KW/6.2KW Nominal Voltage: 24VDC/48VDC Output Voltage: 220VAC/230VAC Input Voltage Range: Appliance mode: 90~280V; UPS mode: 170~264V MPPT Operating Voltage Range: 120-450VDC MPPT: 100A(4.2KW); 80A(6.2KW)

Model Number: CNW330 10-40KVA Nominal Capacity: 10-40KVA Nominal Voltage: 208VAC Maximum Input Voltage Range: ±20% Nominal Frequency: 50/60HZ

Model: CNS110 8000-48 PLUS Nominal Capacity: 8KW Nominal Voltage: 48VDC Output Voltage Range: 184-265VAC Input Voltage Range: 120-280VAC MPPT Operating Voltage Range: 120-450VDC

SPECIFICATION: Model Number: TSS-48400 System capacity：8U400A Input voltage range： 120~425Vdc Output voltage：-53.5Vdc Output current： 400A （MAX） Output capacity: 24KW (MAX) Solar modules quantity: 1~8pcs   CONFIGURATION: Pv input: MCB 25A / 2P * 8, DC-SPD * 8 Battery access: MCB 125A / 1P * 4 DC output: DC-SPD * Class 1-C Secondary load disconnect: MCB 100A / 1P * 2,63A / 1P * 4,32A / 1P * 2 Primary load disconnect: MCB 63A / 1P * 2,32A / 1P * 2,16A / 1P * 2 Secondary load disconnect is controlled by the 400A contactor (normally closed) Primary load disconnect is controlled by the 200A contactor (normally closed) Note: above configurations can be customized.   Application field: Telecom; Data center

SPECIFICATION: Model Number:TRSS-48300 System capacity：9U300A   Solar Charge Controller Module: Input voltage range： 120~425V Output voltage：-54.5Vdc Output current： 300A （MAX） Output capacity: 18KW (MAX) Solar module quantity: 1~6pcs Rectifier modules: Input voltage range： 176~300V Output voltage：-53.5Vdc Output current： 300A （MAX） Output capacity: 18KW (MAX) Solar module quantity: 1~6pcs   CONFIGURATION: AC input: MCB 63A / 3P * 1, UK35 * 1 PV input: MCB 25A / 2P * 6, DC-SPD * 6 Battery access: MCB 125A / 1P * 3 Primary load disconnect: MCB 125A/1P*3, 63A/1P*3 Primary load disconnect is controlled by a 400A contactor (normally closed) Configuration: AC Class C 3 + 1 mode 20 KA / 40 KA SPD * 1, DC output lightning protection: Class C DC SPD * 1 Note: above configurations can be customized.   Application field: Telecom; Data center
